6.16.4 Ethernet interface (HMI) The Electronics Module has an integrated Ethernet inter-
face.
The installed LAN interface allows data visualization via
an Internet-capable device and HTTP protocol or stan-
dard browser. The LAN interface also supports data com-
munication with higher level control systems via Modbus
TCP protocol.
Visualization and operation are effected via the web
pages integrated in the Electronics Module. Wireless
access via mobile devices such as tablet computers or
smartphones is possible by installing a wireless router on-
site and connecting it to the Electronics Module.
The Ethernet interface supports a transmission rate of
100 Mbit/s.
The Ethernet interface is electrically isolated.
Connection is via a standard Ethernet connection cable.
To allow the use of pre-terminated Ethernet cables with
connectors,one special M25 cable gland with slit rubber
seals and larger grommets is installed. The Ethernet con-
nectors can be inserted through these fittings.
The Ethernet connection is designed in accordance with
IEEE 802.3. There is a RJ45 socket installed at the HMI.
Connection to a network is possible using a patch cable
(1:1) or a crossover cable (crossover network cable). The
LEDs are fitted in the RJ45 socket. They display the inter-
face statuses.
HINWEIS
This instruction manual does not cover installation and
commissioning in combination with routers or wireless
routers. Responsibility for this lies with the operator.
• For security reasons, access to the device should
only be granted to authorized personnel.
• Permanent, unsafe connections via the Internet or
WLAN are not permitted. Safe connections can, for
example, be set up via a VPN-secured communica-
tion channel or an encoded WLAN connection.
• The Electronics Module only supports the unen-
crypted communication protocol “http” and is
designed for operation within an Intranet (closed
network) (Chapter Safety - IT security).
