Description and function
6
Rivo™ I Controller EN
47
Evoqua Water Technologies GmbH | W3T597263 Issue 01-0624
Fig. 6 Ethernet connection
The connection runs in Auto negotiation mode. The data
transfer rate and full or half duplex are defined automati-
cally with the connected switch/HUB.
LED Status Meaning
green illuminated Ethernet connection estab-
lished
green flashing Data being transferred
yellow off 10 Base-T
yellow illuminated 100 Base-T
LED (yellow) LED (green)
