Description and function
EN Rivo™ I Controller
34
W3T597263 Issue 01-0624 | Evoqua Water Technologies GmbH
Tp
Meaning: Cycle period
Display: Seconds (s)
Explanation: The parameter Tp only applies to dosing
pumps.
The cycle period Tp defines a switching period, which
must be coordinated with the respective pump type.
Setting range: The parameter Tp can be set from 10 to
180 s.
Example:
Fast dosing pumps correspond to a low Tp;
slow dosing pumps correspond to a high Tp.
The control parameter Tp must always be adjusted to suit
the pump employed:
6.5 Display of dosing quantity
The electronics module allows a freely configurable dos-
ing quantity display (Yout). In the menu, the dosing quan-
tity can be left as a value 0 to 100% or freely configured
as a dosing quantity, e.g. 0 to 10.0 l/h, 0 to 4.0 g/h, etc.
Format and unit are freely selectable - see menu on the
device.
Dosing pump strokes/
min
Tp value
up to 20 120
20 to 40 100
40 to 80 60
80 to 125 30
125 to 200 15
