10.1.1 Icons
Some menus, icons, buttons or terms serve merely as dis-
plays, while others are assigned an underlying function
(interactive menu navigation) or selection option. Values
or terms can be entered, edited or saved in the input
boxes.
Icon Designation
System menu
Language (Icon under system menu)
Alarms - ACK
Log in
Log out
Log out
Log in
Apply
Cancel
Back button
Home button
Service-Center
User administration selection
Operating mode selection
Operating mode “automatic mode“
inactive/active
Icon blue = “automatic mode“ inactive
Icon green = “automatic mode“ active
Operating mode “manual mode“
inactive/active
Icon blue = “manual mode“ inactive
Icon green = “manual mode“ active
Operating mode inaktiv/aktiv
Icon blue = “Operating mode“ inactive
Icon green = “Operating mode“ active
Reset button
Alarm unwiderruflich quittieren
Alarm information
Calibration
Modul information
Trend
Icon Designation
