Evoqua Rivo I - Installation Drawing, Electronics Module

Installation
7
Rivo™ I Controller EN
51
Evoqua Water Technologies GmbH | W3T597263 Issue 01-0624
7.2.3 Installation drawing, Electronics Module
BZ-1588_001
200
( Montageschiene / mounting rail )
5,1
224,5 ( Mitte Montageschiene )
( middle mounting rail )
252
26
5,5
15
45
100
45
190
15
153
5
7
18
25
283
9 9
306
Brackets for hooking onto
tallow-drop screws.
Alternative: Installation with
top-hat rail
Mounting brackets for fix-
ing the housing in position
with tallow-drop screws
