Excelitas Technologies OmniCure S2000 Elite

S2000 Elite - User's Guide
035-00707 Revision 1
19
Figure 4: Lamp Connections
1. Intelli-lamp Connector
2. Grommet
The power connector will only attach in the correct orientation. If there are difficulties
attaching the connector, try rotating it by 180º.
