S2000 Elite - User's Guide
035-00707 Revision 1
84
The latch action will keep the specified output energized until the corresponding
output is de-energized with an unlatch action. If there is no corresponding unlatch
action, the output is only energized momentarily.
This is an unlatch output action. When this element is executed, the corresponding
output is de-energized. This action can be associated with the following elements:
1. Channel 1/2/3 Output (C1/C2/C3)
2. Tree 1/2/3/4 Output (T1/T2/T3/T4)
3. Virtual Output (VO)
The unlatch action will de-energize a previously energized coil from the latch
action.
This is the duration element (DU) where a duration is loaded into a timer. When this
action is executed, a timer will start. Note, the duration element is only valid if it is
placed before/after certain actions. Further details on how to use the duration
element are provided in the tables below.
This is the exposure action which will run an exposure at a specified intensity.
StepCure Element List
The following is the glossary of StepCure elements which can be used to build StepCure
profile.
Action Type / Element Name
• The contact
represents if a foot
pedal was activated
• It is available as a
Normally
Closed/Normally
Open contact
