Excelitas Technologies OmniCure S2000 Elite User Manual

S2000 Elite - User's Guide
035-00707 Revision 1
85
Input
Remote Trigger (RT1/RT2)
N/A
• The contact
represents if the
remote trigger #1 (or
#2) were activated.
Remote triggers are
wired inputs into the
DB-50 connector of
the S2000 Elite
System
• See PLC Connector:
DB50 for more details
on the pin out
• It is available as a
Normally
Closed/Normally
Open contact
Input
Command Line (CMD)
N/A
• The contact
represents if the
command line input
was set
• It is available as a
Normally Open
contact
• The command line
input can be set by
issuing the
appropriate
command through a
connected
communication port
• Refer to the 035-
00724R Software
SDK for more details
Input
Start/Stop (SS)
N/A
• This contact will
evaluate if the
Start/Stop button is
triggered
• It is available as a
Normally Open
contact
Input
NFC Event (NFC)
N/A
• The contact
represents if a valid
NFC card was
