Presets: Pull, Push, or Create Live
When a preset is pulled from the device, the preset data remains in the device until the
preset is recalled. DSPConfigurator pulls the names of the presets only. These presets
cannot be saved to disk until recalled.
An asterisk next to the preset name indicates that only the preset name has been pulled
from the device, and the preset data exists only in the device (it has not been recalled).
Presets pushed to the device or created in DSPConfigurator in live mode, have no
asterisk. Presets with no asterisk can be saved to disk.
Protected Configuration
A protected configuration is secured with PIN protection. The protected configuration can
be recalled by any user, but can only be written or overwritten using the assigned (up to)
4-digit PIN. Utilities for save/recall/changePIN, separate from preset save, are accessed
from the tools menu as three sub-menus under a protected configuration menu item.
Protected configuration menu items are available only in Live mode from the
Tools>Protected Configuration menu. These functions can only be performed in
Live mode, and are unavailable in Emulate mode.
• Save
• Recall
• Change PIN
Save Protected Configuration
The default PIN is 0000. The user enters the default PIN or can use the Change PIN (see
below) dialog to create a new one.
Recall Protected Configuration
The dialog prompts the user to continue. Click OK to continue or Cancel the operation.
Change PIN
The change PIN utility changes a current protected configuration PIN. The current PIN
must be entered before changes are allowed.
DMP128 • Software Control 96
