• Processor Defaults, Reset All Defaults —
Returns the DMP128 processor and level control blocks to
factory default settings. Each processor, and gain/volume/
trim block also has an individual default reset.
• Processor Defaults, Defaults — Individually selects
the default parameters for the various processor, trim, and
gain blocks.
Each row item contains default settings customized for the
processor, filter, trim, or gain block it represents.
Gain and volume blocks can be initially muted, while filter
and dynamics processor blocks can be initially bypassed.
NOTE: The bypass function is labeled Enable.
• To view the individual processor defaults, press [
] to the left of the processor, trim,
gain, or meter device.
• Expansion Bus (live mode only) —
Provides a means to select control of either
the primary or secondary device (see Extron
EXP Bus on page79).
Window Menu
• Cascade — Rearranges all open DSP Configurator program
screens, including dialog boxes, in a cascading array.
• Close All Windows — Closes all open dialog boxes.
• Individual Windows — Lists all open dialog boxes. Clicking on
the name brings the associated dialog box to the front of the desktop.
Help Selection
The Help menu contains the following elements:
• Contents — opens the Help file at the Contents tab.
• Search — opens the Help file at the Search tab.
• About... — displays the name of the application, the current version number, and
copyright information.
NOTE: Help can be activated via the F1 key from any main screen or dialog
(which accesses context sensitive Help).
DMP128 • Software Control 25
