3. From the toolbar, select File>Open.
4. Locate the downloaded firmware file and click it.
5. Click Begin on the main Firmware Loader dialog. The total
progress bar tracks the loading progress.
6. When the upload is finished, exit the program by selecting
File>Exit.
The firmware upload is complete.
Firmware Loader
Extron provides a firmware loader utility that, when installed, allows the firmware
of the DSPConfigurator program to be updated or replaced.
To install upgrade the DMP128 firmware:
• Download, then install the Firmware Loader utility
from www.extron.com.
• Download the desired firmware file from the
Extron website, (see Firmware Upgrade Page
on page161).
To access the firmware loader:
1. From the DSP Configurator toolbar, select
Tools>Firmware Loader.
2. The Add Device dialog box opens. Type the
IP address of the DMP128 in the Hostname or
IPAddress field, then click OK.
NOTE: If the IP has not been changed, the
default IP address is: 192.168.254.254
The Firmware Loader screen opens.
DMP128 • Reference Information 168
