Extron electronics DMP 128 - EXP Outputs Mix Matrix

Virtual Send Bus Mix-points
(from Mic/Line Inputs)
Virtual Send
Bus Mix Matrix
Virtual Send Bus Mix-points
(from Virtual Bus Returns)
EXP Inputs to Virtual Bus
Sends
a
b
c
Virtual Sends Bus Mix Matrix
The Virtual Sends bus mixer can be further broken down into the mic/line inputs (
a
),
virtual bus returns (
b
), and EXP input mix-points (
c
).
DMP128 • Reference Information 185
