Table 6: Mic/Line Inputs to Virtual Sends Mix-points
a
Inputs to Virtual
Sends
X6)
a
Inputs to Virtual
Sends
X6)
Input 1 to Virtual Send A
20009
Input 2 to Virtual Send A
20109
Input 1 to Virtual Send B
20010
Input 2 to Virtual Send B
20110
Input 1 to Virtual Send C
20011
Input 2 to Virtual Send C
20111
Input 1 to Virtual Send D
20012
Input 2 to Virtual Send D
20112
Input 1 to Virtual Send E
20013
Input 2 to Virtual Send E
20113
Input 1 to Virtual Send F
20014
Input 2 to Virtual Send F
20114
Input 1 to Virtual Send G
20015
Input 2 to Virtual Send G
20115
Input 1 to Virtual Send H
20016
Input 2 to Virtual Send H
20116
Input 3 to Virtual Send A
20209
Input 4 to Virtual Send A
20309
Input 3 to Virtual Send B
20210
Input 4 to Virtual Send B
20310
Input 3 to Virtual Send C
20211
Input 4 to Virtual Send C
20311
Input 3 to Virtual Send D
20212
Input 4 to Virtual Send D
20312
Input 3 to Virtual Send E
20213
Input 4 to Virtual Send E
20313
Input 3 to Virtual Send F
20214
Input 4 to Virtual Send F
20314
Input 3 to Virtual Send G
20215
Input 4 to Virtual Send G
20315
Input 3 to Virtual Send H
20216
Input 4 to Virtual Send H
20316
Input 5 to Virtual Send A
20409
Input 6 to Virtual Send A
20509
Input 5 to Virtual Send B
20410
Input 6 to Virtual Send B
20510
Input 5 to Virtual Send C
20411
Input 6 to Virtual Send C
20511
Input 5 to Virtual Send D
20412
Input 6 to Virtual Send D
20512
Input 5 to Virtual Send E
20413
Input 6 to Virtual Send E
20513
Input 5 to Virtual Send F
20414
Input 6 to Virtual Send F
20514
Input 5 to Virtual Send G
20415
Input 6 to Virtual Send G
20515
Input 5 to Virtual Send H
20416
Input 6 to Virtual Send H
20516
Input 7 to Virtual Send A
20609
Input 8 to Virtual Send A
20709
Input 7 to Virtual Send B
20610
Input 8 to Virtual Send B
20710
Input 7 to Virtual Send C
20611
Input 8 to Virtual Send C
20711
Input 7 to Virtual Send D
20612
Input 8 to Virtual Send D
20712
Input 7 to Virtual Send E
20613
Input 8 to Virtual Send E
20713
Input 7 to Virtual Send F
20614
Input 8 to Virtual Send F
20714
Input 7 to Virtual Send G
20615
Input 8 to Virtual Send G
20715
Input 7 to Virtual Send H
20616
Input 8 to Virtual Send H
20716
Input 9 to Virtual Send A
20809
Input 10 to Virtual Send A
20909
Input 9 to Virtual Send B
20810
Input 10 to Virtual Send B
20910
Input 9 to Virtual Send C
20811
Input 10 to Virtual Send C
20911
Input 9 to Virtual Send D
20812
Input 10 to Virtual Send D
20912
Input 9 to Virtual Send E
20813
Input 10 to Virtual Send E
20913
Input 9 to Virtual Send F
20814
Input 10 to Virtual Send F
20914
Input 9 to Virtual Send G
20815
Input 10 to Virtual Send G
20915
Input 9 to Virtual Send H
20816
Input 10 to Virtual Send H
20916
DMP128 • Reference Information 186
