Reinitialize Digital I/O
Should the script stop running for any reason, select
Tools > Configure DigitalI/O > Reinitialize Digital I/O.
This option is only available in live mode.
To remove a digital I/O script from the DMP128:
Only one digital I/O configuration can be active at a time. If the I/O activity requires
modification, remove the current configuration by:
1. From the main menu, select Tools>Configure Digital I/O > Remove
Digital I/O Configuration from the Device and click OK.
2. If the DSP Configurator is connected to a device, the I/O configuration is removed. If it
is not connected, a connection dialog box appears.
3. Make certain the connection information is correct, then click OK. The I/O
configuration script is removed and a confirmation dialog box appears.
Emulate Mode and Live Mode
DSP Configurator has two operational modes, Live and Emulate. In live mode, the
program has established a connection and is synced with the DMP128. Changes affect
the device in real-time and changes in the current state of the device are reflected in
DSPConfigurator. In contrast, emulate mode allows the user to work offline, creating or
editing configurations that do not immediately affect DMP128 operation.
DSP Configurator always starts in Emulate mode. In Emulate mode, all functions of
DSPConfigurator are available without connecting to the DMP128. The user can build
a configuration from the blank screen, or open an existing file that contains the last
configuration displayed plus saved presets. Settings and adjustments are saved to
a configuration file on the PC. When the saved file is opened in DSPConfigurator, all
settings are restored as the current configuration (emulated if in Emulate mode or live if in
Live mode).
Live mode can be entered at any time after program launch, either with a blank
configuration, after creating a configuration, or after loading a previously saved
configuration file.
In emulate mode, the current state is titled Current Emulation. In live mode, the current
state is titled, Current State.
Synchronizing: Pull from or Push to the Device
When switching to live mode, either:
• Pull data from the device and update the program configuration. This
option downloads device settings from the DMP128 and synchronizes it with
DSPConfigurator overwriting the current DSPConfigurator settings, or
• Push data from DSPConfigurator to the device, overwriting settings in the DMP128.
Live mode is also used to tailor audio settings in real time while listening to the audio
output.
DMP128 • Software Control 89
