Extron electronics DMP 128 - Virtual Returns to EXP Outputs Table

a
Inputs to Virtual
Sends
X6)
a
Inputs to Virtual
Sends
X6)
Input 11 to Virtual Send A
21009
Input 12 to Virtual Send A
21109
Input 11 to Virtual Send B
21010
Input 12 to Virtual Send B
21110
Input 11 to Virtual Send C
21011
Input 12 to Virtual Send C
21111
Input 11 to Virtual Send D
21012
Input 12 to Virtual Send D
21112
Input 11 to Virtual Send E
21013
Input 12 to Virtual Send E
21113
Input 11 to Virtual Send F
21014
Input 12 to Virtual Send F
21114
Input 11 to Virtual Send G
21015
Input 12 to Virtual Send G
21115
Input 11 to Virtual Send H
21016
Input 12 to Virtual Send H
21116
Telephone Rx to Virtual Send A
21209
Telephone Rx to Virtual Send B
21210
Telephone Rx to Virtual Send C
21211
Telephone Rx to Virtual Send D
21212
Telephone Rx to Virtual Send E
21213
Telephone Rx to Virtual Send F
21214
Telephone Rx to Virtual Send G
21215
Telephone Rx to Virtual Send H
21216
DMP128 • Reference Information 187
