• Configure Groups — Opens the configure groups dialog box (see Group
Masters on page82).
• Device Settings (live mode only) — Opens a dialog box to change the
IPaddress, set administrator and user passwords, change the device name, change
the date and time, and to select the serial port baud rate.
• Network Audio Control — Launches Dante Controller to facilitate the discovery
of networked audio devices that are compliant with the network audio standard used
by the DMP128. Discovery is invoked upon launch, and retrieves device name, audio
channels, IP address and the MAC address (see Dante Controller Configuration
on page118).
• Phone Dialer — The phone dialer utility opens a dialog box that provides telephone
service capability for answering and initiating calls to remote attendees participating
in a conferencing session (see Telephone Rx (DMP128CP and DMP128CPAT
only) on page58).
• Options — Opens a tabbed dialog box that allows
customization of the DSPConfigurator appearance and
operation.
• Colors — Tailor the appearance of the various graphs
and dialog boxes. Appearance uses a selected
color scheme for the complimentary and graph colors.
Complimentary Colors allows custom selection of
colors used with the various graphs and dialog boxes.
Graph colors change the row colors containing the
information and descriptions of the graphs seen in the
processor blocks.
• Preferences — The startup splash screen contains
options for selection of the devices to connect to, or to
Always ask on startup. That selection can be changed
using Default Device.
• If Show Meters is set to True, Dynamic Block
Meters can be used to tailor the appearance
of the dynamics meters in order to use the full
meter to show input and gain reduction, or to
show the level based on the output and gain
reduction.
DMP128 • Software Control 24
