Command and Response Table for Basic SIS Commands (continued)
Command ASCII command
(host to device)
Response
(device to host)
Additional
description
IP Setup Commands
Set unit name
EX1@
CN
}
Ipn•
X1@]
View unit name
E
CN
} X1@]
Set name to factory default
E
•CN
}
Ipn•
X4(]
Set time and date
EX1#
CT
}
Ipt•
X1#]
View time and date
E
CT
} X1#]
Set GMT offset
EX#
CZ
}
Ipz
X#]
View GMT offset
E
CZ
} X#]
Set Daylight Savings Time
EX3$
CX
}
Ipx
X3$]
Read Daylight Savings Time
E
CX
} X3$]
Set IP address
EX1$
CI
}
Ipi
X1$]
Read IP address
E
CI
} X1$]
Read hardware address
(MAC)
E
CH
} X1*]
Set subnet mask
EX1(
CS
}
Ips
X1(]
Read subnet mask
E
CS
} X1(]
Set gateway IP address
EX1$
CG
}
Ipg
X1$]
View gateway IP address
E
CG
} X1$]
Set DHCP on
E
1DH
}
Idh1
]
Set DHCP off
E
0DH
}
Idh0
]
NOTE: Changing DHCP from On to Off resets the IP address to the factory default (192.168.254.254).
View DHCP status
E
DH
} X%]
Set verbose mode
EX2@
CV
}
Vrb
X2@]
View verbose mode
E
CV
} X2@]
Get connection listing
E
CC
}
[number of connections]
]
NOTES:
X#
= Greenwich Mean Time offset GMT offset value (– 12:00 to 14:00) representing hours and minutes
(HH:MM) local time is offset from GMT time
X%
= On/Off status 0=off/disable
1=on/enable
X1@
= Unit name Alpha-numeric up to 24 characters. No special characters except hyphen (-)
No upper/lower case distinction, no blanks or spaces, first character must be
alpha, last character cannot be hyphen.
X1#
= Local date/time Set: MM/DD/YY-HH:MM:SS
Read: day of week, date, month, year HH:MM:SS
(for instance; Fri, 21 Jun 2002 10:54:00)
X1$
= IP Address default 192.168.254.254
X1*
= Hardware MAC address 00-05-A6-xx-xx-xx
X1(
= Subnet mask Default 255.255.0.0
X2@
= Verbose/Response mode 0=clear (default for IP), 1=verbose (default for serial and USB),
2=tagged responses, 3=verbose + tagged responses
X3$
= Daylight Saving time 0=off/ignore;
1= USA (begins second Sunday in March/ends first Sunday in November);
2= Europe (begins last Sunday in March/ends last Sunday in October);
3= Brazil (begins third Sunday in October/ends third Saturday in March).
X4(
= Alpha-numeric unit name combination of unit name and last three pairs of MAC address
DMP128 • SIS Programming and Control 136
