Command ASCII command
(host to device)
Response
(device to host)
Additional description
Protected configuration
NOTE: The DMP128 can save and recall a Personal Identification Number (PIN)-protected configuration, which includes all
processing and levels in the current coinfiguration, with the exception of the IP address). The protected configuration is
useful to establish the DMP128 in a known state, either as a troubleshooting tool or as a baseline configuration.
Save the configuration
E
S
X7)
PCFG
}
PcfgS
]
Save the configuration to the
protected memory location.
Recall the configuration
E
RPCFG
}
PcfgR
]
Recall the protected configuration
Change the PIN
E
P
X7)
old
*
X7)
new
PCFG
}
PcfgP
X7)
new
]
Overwrite the old PIN
(
X7)
old
) with the new one (
X7)
new
).
Query configuration saved
status
E
QPCFG
} X7!]
NOTES:
X7)
= Personal Identification Number (PIN) Four numeric digits, default = 0000
X7!
= Protected configuration status 0 = no protected configuration saved
1 = protected configuration saved
Command and Response Table for DSP SIS Commands (continued)
DMP128 • SIS Programming and Control 145
