Once a processor is inserted, to view associated parameters that define the selected
processor (such as a frequency curve) or to remove the bypass, double-click the
processor block. This action opens a new dialog box with parameters for the process (see
figure20).
Figure 20. Sample Processor Dialog Box
• Click Set Defaults to discard all custom settings and
reload the default parameters.
• Click Bypass to temporarily suspend processing without
removing the processor block. Red indicates the processor is bypassed.
By default, a processor block is bypassed when inserted (the Bypass button in the
processor dialog box is red).
NOTE: Figure 20 is an example of one type of dialog box. Contents and appearance
of each dialog box are unique to the processor type.
The block can be removed from the signal chain by clicking it to bring focus and pressing
<Delete> or by right-clicking and selecting Delete.
Detailed explanations of each signal chain with their processor blocks along with mix-point
operation follow in the next section.
DMP128 • Software Control 29
