Extron electronics IN1608 xi IPCP SA with LinkLicense User Manual

IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 59
Command ASCII Command
(Host to scaler)
Response
(Scaler to host)
Additional Description
Input Configuration Commands (continued)
Pixel phase (available only for RGB and YUV-HD input signals)
Specify a value
EX%
PHAS
}
Phas
X!
*
X%]
Set the pixel phase to
X%
on the
current input.
Increment value
E
+PHAS
}
Phas
X!
*
X%]
Increase the pixel phase by one on
the current input.
Decrement value
E
-PHAS
}
Phas
X!
*
X%]
Decrease the pixel phase by one on
the current input.
View
E
PHAS
} X%]
In verbose modes 2 and 3:
Phas
X!
*
X%]
View the pixel phase of the current
input.
Total pixels (available only for RGB and YUV-HD input signals)
Specify a value
EX^
TPIX
}
Tpix
X!
*
X^]
Set the total pixels to
X^
on the
current input.
Increment value
E
+TPIX
}
Tpix
X!
*
X^]
Increase the total pixels by one on
the current input.
Decrement value
E
-TPIX
}
Tpix
X!
*
X^]
Decrease the total pixels by one on
the current input.
View
E
TPIX
} X^]
In verbose modes 2 and 3:
Tpix
X!
*
X^]
View the total pixels setting on the
current input.
Active pixels
Specify a value
EX&
APIX
}
Apix
X!
*
X&]
Set the active pixels to
X&
on the
current input.
Increment value
E
+APIX
}
Apix
X!
*
X&]
Increase the active pixels by one on
the current input.
Decrement value
E
-APIX
}
Apix
X!
*
X&]
Decrease the active pixels by one on
the current input.
View
E
APIX
} X&]
In verbose modes 2 and 3:
Apix
X!
*
X&]
View the active pixels on the current
input.
NOTES:
X!
= Input selection
1-8
X%
= Pixel phase
0-63 (31 = default)
X^
= Total pixels
±512 of the default value
X&
= Active pixels
±256 of the default value
