IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 60
Command ASCII Command
(Host to scaler)
Response
(Scaler to host)
Additional Description
Input Configuration Commands (continued)
Active lines
Specify a value
EX*
ALIN
}
Alin
X!
*
X*]
Set the active lines to
X*
on the
current input.
Increment value
E
+ALIN
}
Alin
X!
*
X*]
Increase the active lines by one on
the current input.
Decrement value
E
-ALIN
}
Alin
X!
*
X*]
Decrease the active lines by one on
the current input.
View
E
ALIN
} X*]
In verbose modes 2 and 3:
Alin
X!
*
X*]
View the active lines of the current
input.
3:2, 2:2, 24:1 Film mode detect
Auto
EX!
*1FILM
}
Film
X!
*
X1@]
Set film mode detection to
automatic (default).
Off
EX!
*0FILM
}
Film
X!
*
X1@]
Disable film mode detection.
View setting
EX!
FILM
} X1@]
In verbose modes 2 and 3:
Film
X!
*
X1@]
View the current film mode setting.
Picture Adjustment Commands
Video mute for individual outputs (defaults to unmuted after a power cycle)
Set video mute for an
individual output
X@
*
X2(
B Vmt
X@
*
X2(]
Mute the video or the video and
sync, or unmute output
X@
only.
View individual output mute
status
X@
*B
X2(]
In verbose modes 2 and 3:
Vmt
X@
*
X2(]
View the mute status of output
X@
.
Video mute for all outputs (defaults to unmuted after a power cycle)
Mute video to black
1B
Vmt1
]
Mute video to black on all outputs.
Mute sync and video
2B
Vmt2
]
Mute video and sync on all outputs.
Unmute sync and video
0B
Vmt0
]
Unmute all outputs.
View mute status on all
outputs
B
X5%]
In verbose modes 2 and 3:
Vmt
X5%]
View the mute status on all outputs.
NOTES:
X!
= Input selection
1-8
X@
= Output selection
1 = Output 1A – HDMI (top connector)
2 = Output 1B – HDMI (bottom connector)
3 = Output 1C – DTP/HDBT
X*
= Active lines
±256 of the default value
X1@
= Film detect mode
0 = disabled, 1 = auto (default)
X2(
= Video mute for individual outputs
0 = unmute
1 = mute video
2 = mute video and sync
X5%
= Video mute on all outputs
0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is disabled
