IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 61
Command ASCII Command
(Host to scaler)
Response
(Scaler to host)
Additional Description
Picture Adjustment Commands (continued)
Color (NTSC, PAL, and SECAM inputs only)
Specify a value
EX1%
COLR
}
Colr
X!
*
X1%]
Set the color level on the current
input.
Increment value
E
+COLR
}
Colr
X!
*
X1%]
Increase the color level by one.
Decrement value
E
-COLR
}
Colr
X!
*
X1%]
Decrease the color level by one.
View
E
COLR
} X1%]
In verbose modes 2 and 3:
Colr
X!
*
X1%]
View the color level setting.
Tint (NTSC inputs only)
Specify a value
EX1%
TINT
}
Tint
X!
*
X1%]
Set the tint on the current input.
Increment value
E
+TINT
}
Tint
X!
*
X1%]
Increase the tint by one.
Decrement value
E
-TINT
}
Tint
X!
*
X1%]
Decrease the tint by one.
View
E
TINT
} X1%]
In verbose modes 2 and 3:
Tint
X!
*
X1%]
View the tint setting.
Contrast
Specify a value
EX1%
CONT
}
Cont
X!
*
X1%]
Set the contrast for the current input.
Increment value
E
+CONT
}
Cont
X!
*
X1%]
Increase the contrast by one.
Decrement value
E
-CONT
}
Cont
X!
*
X1%]
Decrease the contrast by one.
View
E
CONT
} X1%]
In verbose modes 2 and 3:
Cont
X!
*
X1%]
View the contrast setting.
Brightness
Specify a value
EX1%
BRIT
}
Brit
X!
*
X1%]
Set the brightness on the current
input.
Increment value
E
+BRIT
}
Brit
X!
*
X1%]
Increase the brightness by one.
Decrement value
E
-BRIT
}
Brit
X!
*
X1%]
Decrease the brightness by one.
View
E
BRIT
} X1%]
View the brightness setting.
Detail filter
Specify a value
EX1%
HDET
}
Hdet
X!
*
X1%]
Set the detail filter for the current
input to
X1%
.
Increment value
E
+HDET
}
Hdet
X!
*
X1%]
Increase the detail by one.
Decrement value
E
-HDET
}
Hdet
X!
*
X1%]
Decrease the detail by one.
View
E
HDET
} X1%]
In verbose modes 2 and 3:
Hdet
X!
*
X1%]
View the detail filter setting.
NOTES:
X!
= Input selection
1-8
X1%
= Picture adjustment
0-127 (64 = default)
