IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 62
Command ASCII Command
(Host to scaler)
Response
(Scaler to host)
Additional Description
Picture Adjustment Commands (continued)
Horizontal shift (image)
Specify a value
EX1^
HCTR
}
Hctr
X1^]
Set the horizontal position to
X1^
.
Increment value
E
+HCTR
}
Hctr
X1^]
Increase the horizontal position by
one.
Decrement value
E
-HCTR
}
Hctr
X1^]
Decrease the horizontal position by
one.
View
E
HCTR
} X1^]
In verbose modes 2 and 3:
Hctr
X1^]
View the horizontal position setting.
Vertical shift (image)
Specify a value
EX1&
VCTR
}
Vctr
X1&]
Set the vertical position to
X1&
.
Increment value
E
+VCTR
}
Vctr
X1&]
Increase the vertical position by one.
Decrement value
E
-VCTR
}
Vctr
X1&]
Decrease the vertical position by
one.
View
E
VCTR
} X1&]
In verbose modes 2 and 3:
Vctr
X1&]
View the vertical position setting.
Horizontal size (image)
Specify a value
EX1*
HSIZ
}
Hsiz
X1*]
Set the horizontal size to
X1*
.
Increment value
E
+HSIZ
}
Hsiz
X1*]
Increase the horizontal size by one.
Decrement value
E
-HSIZ
}
Hsiz
X1*]
Decrease the horizontal size by one.
View
E
HSIZ
} X1*]
In verbose modes 2 and 3:
Hsiz
X1*]
View the horizontal size setting.
Vertical size (image)
Specify a value
EX1(
VSIZ
}
Vsiz
X1(]
Set the vertical size to
X1(
.
Increment value
E
+VSIZ
}
Vsiz
X1(]
Increase the vertical size by one.
Decrement value
E
-VSIZ
}
Vsiz
X1(]
Decrease the vertical size by one.
View
E
VSIZ
} X1(]
In verbose modes 2 and 3:
Vsiz
X1(]
View the vertical size setting.
Compound image position and size
Specify a value
EX1^
*
X1&
*
X1*
*
X1(
XIMG
}
Set the horizontal and vertical
positions as well as the horizontal
and vertical sizes.
Ximg
X1^
*
X1&
*
X1*
*
X1(]
View
E
XIMG
} X1^
*
X1&
*
X1*
*
X1(]
View all position and size settings.
In verbose modes 2 and 3:
Ximg
X1^
*
X1&
*
X1*
*
X1(]
NOTES:
X1^
= Horizontal position
±2048
X1&
= Vertical position
±1200
X1*
= Horizontal size
10-4096
X1(
= Vertical size
10-2400
To Next Page
