Screen Mix Controls
The Mixer Screen
Tiles
A Tile shows basic information about the Feed it represents.
Bus tiles show only fader information. Track Feed and Live Feed tiles display more information,
and provide control for a group of functions, as shown below.
Live Feed tiles
Track Feed tiles “Called” channel
Sub-bus tiles Aux bus tiles Main bus Automation
Fat Channel
