User Manual METERS February 16, 2010
Xynergi Media Production Centre Page 207
Peak Hold Time
Peak hold time can be set in the Meters Menu as follows:
Step 1 Press the
Meters button.
Step 2 Press the
Peak Hold soft key repeatedly to choose Off, Short, Long or Permanent peak hold.
Overload Hold Time
Overload hold time can be set in the Meters Menu as follows:
Step 1 Press the
Meters button.
Step 2 Press the
Over Hold soft key.
Step 3 Use the Jog Wheel to change the overload hold time.
Step 4 Press the
Enter key, or the Exit soft key
Meter Point
The Meter Point is the place in a channel where level is extracted for metering. To move the meter point
for all signal paths:
Step 1 Press the
Meters button.
Step 2 Press the
Mtr Pnt soft key repeatedly to move the meter point.
The meter point can be seen in the Fat Channel by the position of the meter graphic.
