Operator's instruments and controls
2018-02-20 4812325559EN 11
Operator's Control Keyboard
10. Steering turning light
11. Machine warning light – yellow
12. Machine warning light – red
13. High beam
14. Working lights
15. Rear working lights
16. Front working lights
17. Night working lights (Optional)
18. Rear working lights (Optional)
19. Front working lights (Optional)
20. Enable the regeneration (Tier IV Engine)
21. Empty
22. Engine radiators assembly cleaning
23. Disable the regeneration (Tier IV Engine)
24. Brake test
25. Horn
Speed lever
The equipment has four speeds forward and four speeds
backwards completely automatic. (Powershift).
Position the lever forward or backward, according to the desired
direction. On middle position, the transmission will be neutral.
Fig. – Speed lever
12
13
11
25
23
24
20
21
17
18
19
15
16
10
14
22
Gears
Forward
Reverse
