Operation
Under no circumstances, the machine should be
distanced from the ground. The operator must
keep seated on the operator's seat during the
operation.
Make sure that all areas ahead and behind the
machine are free.
1. The selected gear will be the highest one in which the
machine will operate. To select the gear, turn the speed
lever to the gear desired or put the lever to the "4" position
for a fully automatic operation.
The machine speed will be controlled via the
transmission electronic module within the range
chosen according to the accelerator position. The
speed obtained will be always within the range
chosen by the operator. For example: if the operator
selects the 2
nd
gear, the machine speed will be
restricted between the 1
st
and 2
nd
gears, at most.
2. Put the Forward/Reverse lever to the desired travel
direction.
Never exceeds 12.5 mph (20 km/h) during the
tamping and travel operations at the job's site. This
operation may cause discomfort, as well as damage
in the machine. The machine was designed to have
a productivity with speed lower to 12.5 mph (20
km/h).
NOTE: Put, smoothly, the lever in the desired position.
Check if the lock of the "neutral" position is
unlocked.
In certain ground conditions, the highest
selected speed (normally the fourth gear) will
not be reached.
