Fayat DYNAPAC CT3000 - Replace the Front and Rear Axle Oil

Maintenance – By-annually (Every 1,000 hours of operation)
90 4812325559EN 2018-02-20
Replace the front and rear axle oil (initial)
This oil replacement should be done only with
100 hours of operation. The other ones should
be done every 1,000 hours.
Never perform maintenance under the machine
when the engine is running. Always park the
machine on a leveled ground and shim the cylinders.
1. Make sure that the machine is on a leveled ground and the
parking brake is applied.
2. Clean the area around the drainage plug (1) and remove the
refueling plug (2).
3. Release and remove the drainage plug and drain the oil in a
proper container.
4. Install the drainage plug and tighten it with a 69 lb.ft (93 N.m)
torque.
5. Refill with the recommended oil until the edge of the refueling
plug.
Fig. – Differential axle
1
2
