Fayat DYNAPAC CT3000 - Check the Front and Rear Axle Oil Level; Check the Parking Brake Disc and Pads

Maintenance – Monthly (Every 250 hours of operation)
78 4812325559EN 2018-02-20
Check the front and rear axle oil level
Never perform maintenance under the machine
when the engine is running. Always park the
machine on a leveled ground and shim the cylinders.
1. Make sure that the machine is on a leveled ground and the
parking brake is applied.
2. Clean the area around the refueling plug (2).
3. Loose and remove the refueling plug and check the oil level.
The correct level can be found when the oil flows out from
the plug hole.
4. Fill it with the recommended oil, if necessary, through the
refueling plug until it reaches the correct level.
5. Install the drainage plug and tighten it with a 69 lb.ft (93 N.m)
torque.
Check the parking brake disc and pads
1. Check the parking brake pads for wear. Replace the pads if
their thickness is less than 6 mm.
2. Check if the thickness of the disc (3) has any cracks or splits
and if the friction surface is damaged or excessively
scratched. Replace the disc if the thickness is less than 10
mm and if any of the above mentioned defects exist.
Fig. – Differential axle
Fig. – Parking brake disc
1
2
3
