Maintenance - Weekly (Every 50 hours of operation)
70 4812325559EN 2018-02-20
Weekly (Every 50 hours of operation)
Check the tire pressure
Tire pressure should be checked when the tires are cold.
• Normal pressure: 3.1 bar (45 psi)
• Maximum pressure: 4.1 bar (60 psi) – When used for
compactation
• Maximum pressure: 6.9 bar (100 psi) – When used as dozer
When replacing the tires, it’s important to know that
they have the same diameter and original width,
otherwise they can slide into the cylinder or unable
its installation.
Check the tightening of the wheel bolts
The wheel bolts should be tightening crossed, alternately and
opposite to each other.
Bolts dry torque: 545 lb.ft (740 N.m)
Fig. – Wheel, tire and compacting cylinder
Fig. – Wheel, tire and compacting cylinder
