Operation (cont.)
3. Press the acceleration pedal (1). The speed will increase
according to the pressure on the pedal.
Check that the steering system of the machine
is working properly, turning the steering wheel
to the left and right with the machine parked.
NOTE: Do not change the travel direction when the machine is
traveling.
The transmission electronic module does not allow
sudden reversing while traveling, because this
action can damage the transmission box.
4. During the operation, check if all the indicators indicate that,
all readings re normal and all warning lamps are off.
The display will show if any function is above its
specific limit and an alert will sound. If a warning
alert is activated, stop the machine immediately
and check for failure.
Fig. – Acceleration pedal
Fig. – Multifunction display
