Maintenance – Monthly (Every 250 hours of operation)
80 4812325559EN 2018-02-20
Replace the lubricant oil and the engine oil filter
(cont.)
1. Clean the area around the engine base of the oil filter.
2. Remove the filter element (3) with a belt wrench and discard
it.
3. Clean inside the base of the filter and the housing of the seal
ring.
4. After draining all the crankcase oil, install the drainage plug
and tighten it.
5. Fill the new filter element with new oil recommended by
DYNAPAC and lubricate the seal rings with the same oil.
Use only engine oil recommended by DYNAPAC.
Install the element, screwing it manually until it reaches the base
of the filter, then adjust it with another ½ turn. Do not adjust it
excessively, because the seal ring may be damaged and it may
cause leaks.
6. Fill the engine again with the new engine oil recommended
by DYNAPAC, with the proper amount, through the filler
nozzle (1).
7. Wait a few minutes until the oil is entirely inside the
crankcase.
8. Pull the dipstick (2) out ; clean it with a clean cloth, without
threads.
9. Put the dipstick back all the way to the end and pull it out
again.
10. The oil level should be between the marks “FULL” and
“ADD” of the dipstick. If the level is not on the mark ADD or
below it, fill it with new engine oil, according to DYNAPAC
specifications.
11. Fill enough oil so that the level is near the mark “FULL”,
through the filler nozzle (1).
Never fill the engine oil over the “FULL” mark.
12. Close the oil filler nozzle and the engine compartment caps.
Fig. – Engine oil dipstick and filler nozzle
Fig. – Dipstick
Fig. – Engine oil filter
3
1
2
