A. Technical appendix
A−5
Festo P.BE−CPEA−CL−E N en 0711a
Technical specifications Type CP−E16−KL−CL
General technical data See section A.1.1
Protection class as per EN 60 529 IP20
Digital inputs
 Configuration 16 inputs as per IEC 1131−2 type 2 inputs 24 V DC,
positive or negative switching
 Logic level
1−signal
0−signal
≥ 8.6 V
≤ 6 V
 Current consumption (at 24V) (input cur
rent from sensor to input)
At logical 1"
Typ. 8 mA
 Response delay (at 24 V) Typical 3 ms
Sensor voltage supply
 Rated value (protected against incorrect
polarity)
 Tolerance
Via the CP connection
24 V DC
See manual for CP master
 Internal current consumption of the elec
tronics via the CP connection (all inputs in
0−status)
<35 mA
Load capacity Total >0.8 A (electronic short−circuit protection)
Electrical isolation None
Tab.A/3: Technical specifications type CP−E16−KL−CL
