5. Output module type CP−A08−M12−EL−Z
5−3
Festo P.BE−CPEA−CL−E N en 0711a
5.1 Function of the output module type CP−A08−M12−EL−Z
Output module type CP−A08...−M12−EL−Z provides eight uni
versally usable digital outputs for controlling low−current con
suming devices (bulbs, further valves etc.).
Product illustration
Type Explanation
Actuator connections via 8 sockets with M12 thread
CP−A08−M12−EL−Z Provides 8 PNP outputs (IP65). CP module
CP−A08−M12−EL−Z has channel−by−channel
monitoring of short circuit/overload of the outputs.
Tab.5/1: Overview of output modules
