A.1.4 Technical specifications of the EL input modules
Technical specifications TypeCP−E32−M8−EL
General technical data See section A.1.1
Protection class as per EN 60 529; plug con
nector inserted or fitted with protective cap
IP65
Digital inputs
 Configuration 32 inputs per IEC 1131−2 type 2,
24 V DC, positive−switching (PNP)
 Logic level:
1−signal
0−signal
>11 V
< 5 V
 Current consumption (at 24V) (input cur
rent from sensor to input)
At logical 1"
Typ. 8 mA
 Response delay (at 24 V) Typ. 3 ms, can be parametrised: 0.5 ms, 3 ms, 10 ms,
20 ms
Sensor voltage supply
 Nominal value
 Tolerance
Via the CP connection
24 V DC
See manual for CP master (20.4 V ... 26.4 V)
 Internal current consumption of the elec
tronics via the CP connection (all inputs in
0−status)
Max. 75 mA at 24 V
Load capacity Total max. 1.35 A / 500 mF (electronic short−circuit
protection)
Electrical isolation None
Tab.A/5: Technical data type CP−E32−M8−EL
