4.5.2 Diagnostics using fieldbus
Depending on the CPI/CP master used, the CP modules type
CP−...−EL provide different diagnostic information on fault
searching.
Master
Diagnostics of
short circuit/over
load in sensor
supply
Diagnostics,
undervoltage,
sensor supply
CP master
(without extended
functions)
Yes No
CPI master
(with extended
functions)
Yes Yes
Tab.4/7: Diagnostic information
Note
Instructions on evaluating the diagnostic message can be
found in the manual for the relevant CPI/CP master.
