A.1.5 Technical specifications of the EL output modules
Technical data Type CP−A08−M12−EL−Z
General technical data See section A.1.1
Protection class as per EN 60 529; plug con
nector inserted or fitted with protective cap
IP65
Digital outputs
 Configuration
 Load capacity per digital output
8 outputs as per IEC 1131−2;
24 V DC positive−switching
Max. 0.5 A
 Electronic fuse per channel
(short circuit/overload)
Trigger current
Response characteristics
Min. 1.0 A
Slow−blowing
Actuator supply
 Nominal value
 Tolerance
24 V DC
24 V DC ±25% (18 V ... 30 V)
Internal current consumption of the elec
tronics via the CP connection (all outputs
in 0−status)
Max. 35 mA at 24 V
Electrical isolation None
Tab.A/7: Technical data type CP−A08−M12−EL−Z
