4. Input modules type CP−E16−M...−EL and CP−E32−M8−EL
4−9
Festo P.BE−CPEA−CL−E N en 0711a
4.3 Labelling of inscription label holder
Inscription label holders with part number 547473 (type
ASCF−H−E2) are provided for labelling the EL modules. You
can find the dimensions of the inscription field in Fig.4/6.
approx. 60
approx. 24
Fig.4/6: Inscription label holders for EL modules,
type ASCF−H−E2 (dimensions in mm)
