1. System overview CPI/CP system
1−3
Festo P.BE−CPEA−CL−E N en 0711a
1.1 Setting up CPI systems
Festo can assist you in solving your automation task at
the machine level with the aid of valve terminals. Due to
their modular structure, the CP valve terminals from Festo
will enable you to include valve terminals and I/O modules
optimally in your machines and systems.
2
3
45
1
1
CPI fieldbus node
2 MPA−CPI valve terminal
3 CPV−CPI valve terminal
4 CP−CL module
5 CP−EL module
Fig.1/1: Example: Setting up a CPI system
