A.1.2 Technical specifications of the CL input modules
Technical specifications TypeCP−E08−M12−CL, type CP−E08−M8−CL
General technical data See section A.1.1
Protection class as per EN 60 529; plug con
nector inserted or fitted with protective cap
IP65/I P67
Digital inputs
 Configuration 8 inputs per IEC 1131−2 type 2,
24 V DC, positive−switching (PNP)
 Logic level:
1−signal
0−signal
>11 V
< 5 V
 Current consumption (at 24V)
(input current from sensor to input)
At logical 1"
Typ. 8 mA
 Response delay (at 24 V) Typical 3 ms
Sensor voltage supply
 Nominal value
 Tolerance
Via the CP connection
24 V DC
See manual for CP master
 Internal current consumption of the elec
tronics via the CP connection (all inputs in
0−status)
<35 mA
Load capacity Sum > 0.8 A (electronic short−circuit protection)
Electrical isolation None
Tab.A/2: Technical specifications type CP−E08−M12−CL and type CP−E08−M8−CL
