5.5.2 Diagnostics using fieldbus
Irres pe ct i ve of the CPI/CP master used, the CP output module
type CP−...−EL provides diagnosti c information on fault searching.
Master
Diagnostics of
short circuit/over
load in actuator
supply
Diagnostics,
undervoltage,
actuator supply
CP master
(without extended
functions)
Common fault message
CPI master
(with extended
functions)
Yes Yes
Tab.5/8: Diagnostic information
Note
Instructions on evaluating the diagnostic message can be
found in the manual for the relevant CPI/CP master.
