2. Input modules types CP−E08−M...−CL and CP−E16−KL−CL
2−13
Festo P.BE−CPEA−CL−E N en 0711a
The CPI modules are connected sequentially. The M9 plug is
the incoming interface; the M9 socket is the continued inter
face (see Fig.2/1 to Fig.2/3).
If the continuing CP connection is not used:
· Seal the CP connection with a protective cap type
FLANSCHDOSE SER.712, part no. 356684 (accessories).
Only in this way can you comply with protection class
IP 65/IP67.
Note
The continuing CP connection can only be used in conjunc
tion with a CP master with extended functions.
