2. Input modules types CP−E08−M...−CL and CP−E16−KL−CL
2−16
Festo P.BE−CPEA−CL−EN en 0711a
Status LEDs
Status display for input
Only with types CP−E08−M12−CL and CP−E08−M8−CL:
Next to the sensor connections there is a green LED for
every input. This shows the status of the signal at the
relevant input.
LED status of
input
Status
LED lights up
Logical 1 (signal present)
LED is out
Logical 0 (no signal)
Tab.2/5: Status LEDs for status display of input
