3. Output module type CP−A04−M12−CL
3−9
Festo P.BE−CPEA−CL−E N en 0711a
The following functions are provided for the module via the
CPI/CP cable:
Operating voltage for internal electronics
Connection for data exchange
Operating voltage for the connected actuators
The CPI modules are connected sequentially. The M9 plug is
the incoming interface; the M9 socket is the continued inter
face (see Fig.3/1).
If the continuing CP connection
is not used:
· Seal the CP connection with a protective cap type
FLANSCHDOSE SER.712, part no. 356684 (accessories).
Only in this way can you comply with protection class
IP65/IP67.
Note
Check within the framework of your EMERGENCY STOP
circuit, to ascertain the measures necessary for putting
your machine/system into a safe state in the event of an
EMERGENCY STOP (e.g. switching off the operating voltage
for the valves and output modules, switching off the com
pressed air).
