4. Input modules type CP−E16−M...−EL and CP−E32−M8−EL
4−15
Festo P.BE−CPEA−CL−E N en 0711a
The CPI modules are connected sequentially. The M9 plug is
the incoming interface; the M9 socket is the continued inter
face (see Fig.4/1 to Fig.4/3).
If the continuing CP connection is not used:
· Seal the CP connection with a protective cap type
FLANSCHDOSE SER.712, part no. 356684 (accessories).
Only in this way can you comply with protection class
IP65.
Note
The continuing CP connection can only be used in conjunc
tion with a CPI master (with extended functions).
