5. Output module type CP−A08−M12−EL−Z
5−12
Festo P.BE−CPEA−CL−EN en 0711a
The following functions are provided for the module via the
CPI cable:
Operating voltage for internal electronics
Connection for data exchange
The CPI modules are connected sequentially. The M9 plug is
the incoming interface; the M9 socket is the continued inter
face (see Fig.5/1).
If the continuing CP connection is not used:
· Seal the CP connection with a protective cap type
FLANSCHDOSE SER.712, part no. 356684 (accessories).
Only in this way can you comply with protection class
IP65.
Note
Check within the framework of your EMERGENCY STOP
circuit, to ascertain the measures necessary for putting
your machine/system into a safe state in the event of an
EMERGENCY STOP (e.g. switching off the operating voltage
for the valves and output modules, switching off the com
pressed air).
