1. Installation
1-23
Festo P.BE-CPX-PNIO-EN en 1407c English
Bus node +
network
plug
Cable specification
1)
CPX-FB33
+ ...D12G 4...
– Cable type: Ethernet twisted-pair cable, shielded
(Shielded Twisted Pair, STP)
– Transmission class
(link c lass): category Cat 5
– Cable diameter: 6 ... 8 mm
– Wire cross section: 0.14 ... 0.75 mm
2
;
22 AWG required for max. connec tion length
between network participants (PROFI NET-End-to-end-Link)
– Connection length: max. 100 m PROFIN ET-End-to-end-Link
CPX-M-FB34
+ ...RJ45...
– Cable type: Ethernet twisted-pair cable, shielded
(Shielded Twisted Pair, STP)
– Transmission class
(link c lass): category Cat 5
– Cable diameter: 5 ... 8 mm
– Wire cross section: 0.13 ... 0.36 mm
2
(Z ca. 26 ... 22 AWG);
22 AWG required for max. connec tion length
between network participants (PROFI NET-End-to-end-Link)
– Wire/conductor
configuration: 1-wire or 7-wire
– Connection length: max. 100 m PROFIN ET-End-to-end-Link
CPX-M-FB35
+ ...S CRJ...
– Cable type: fibre-optic cable, polymer-optic fibre
(polymeric/plastic optical fibre, POF)
– cable composition
(core/sheath
diameter): 980/1000 ìm
– Cable diameter: 6.5 ... 9.5 mm
– Connection length: max. 50 m PROFIN ET-End-to-end-Link
– Signal attenuation: ≤ 12.5 dB
(over the entire connection length)
1) Length corresponding to specification for PROFINET networks (PROFINET Installation Guide)
based on ISO/IEC 11801, ANS I/TIA/E IA-568 ( see also section 1.6.1)
 www.profinet.com, www.profibus.com/download/
Tab. 1/6: Overview of line specification (in combination with Festo bus node and Festo
network plug)
