2. Commissioning
2-7
Festo P.BE-CPX-PNIO-EN en 1407c English
Electricmodules–busnode Module type Module
indicator
1)
Allocated address
space
(Designation) (Name) Inputs Outputs
Remote Controller operating mode
with setting of data field size 8 byte I /
8byteO(see Tab. 1/4)
CPX-FB33
CPX-M-FB34
CPX-M-FB35
e.g. FB33-RC
ProfiNet I/O
bus node
1)
8byte/
32 I
8byte/
32 O
Remote Controller operating mode
with setting of data field size 16 byte I /
16 byte O (see Tab. 1/4)
CPX-FB33
CPX-M-FB34
CPX-M-FB35
e.g. FB33-RC
ProfiNet I/O
bus node
1)
16 byte/
64 I
16 byte/
64 O
1)
Modu l e iden ti fier in the operator un it or in the hardware confi gu rati on of the programmi n g software
Note.: In the operator unit, the bus node is designated with “FB33-RC Profi Net I/O bus node ” or
“FB34-RC ProfiNet RJ45 bus node” or “FB35-RC ProfiNet FOC bus node”
Tab. 2/1: Addres s as signmen t of th e bus no d e fo r th e Remot e Con tro l l e r ope ra ti n g mode
Electricmodules–busnode
Module type Module
indicator
1)
Allocated address
space
(Designation) (Name) Inputs Outputs
Remote I/O operating mode
without diagnostic access or for set-
ting the diagnostics mode via the
hardware configuration
(from Revision 21, see Tab. 1/2)
CPX-FB33
CPX-M-FB34
CPX-M-FB35
e.g. FB33-RIO
ProfiNet Re-
mote I/O
1)
– –
Remote I/O operating mode
with status bits [Status]
CPX-FB33
CPX-M-FB34
CPX-M-FB35
e.g. FB33-RIO
ProfiNet Re-
mote I/O
1)
[Status]
2byte/
8 (16) I
2)
(8 bit
used)
–
Remote I/O operating mode
with I/O diagnostics interface
[System Table Interface, STI]
CPX-FB33
CPX-M-FB34
CPX-M-FB35
e.g. FB33-RIO
ProfiNet Re-
mote I/O
1)
[STI]
2byte/
16 I
2byte/
16 O
1)
Modul identifier in the operator unit or in the hardware configuration o f the programming software
Note: In the operator unit, the bus node is designated with “FB33-RIO ProfiNet Remote I/O”
or “FB34-RIO ProfiNet RJ45 Remote I/O” or “FB35-R IO ProfiNet FOC Remote I/O”
(independent of the diagnostics mode)
2)
Diagnostics mode status bits occupies 16 I or 2 bytes of address space (8 I or 8 bits remain unused)
Tab. 2/2: Address assignment of the bus nodes for the Remote I/O operating mode
