2. Commissioning
2-8
Festo P.BE-CPX-PNIO-E N en 1407c English
Electric modules Module type Module
indicator
1)
Allocated address
space
(Designation) (Name) Inputs Outputs
Digital 4-off input module CPX-4DE 4DI
Input module
1byte/
4(8)I
3)
–
Digital 8-off input module CPX-8DE 8DI
Input module
1byte/
8I
–
Digital 8-off input module
with channel diagnostics
CPX-8DE-D 8DI-D
Input module
1byte/
8I
–
Digital 8-off input module, n-switching: CPX-8NDE 8NDI
Input module
1byte/
8I
–
Digital 1 6-off input module CPX-16DE 16DI
Input module
2byte/
16 I
–
Digital 1 6-off input module
with channel diagnostics
CPX-M-16DE-
D
16DI-D
Input module
2byte/
16 I
–
Digital 4-off output module CPX-4DA 4DO
Output module
– 1byte/
4(8)O
2)
Digital 8-off o utput module CPX-8DA 8DO
Output module
– 1byte/
8O
Digital 8-off high-current out put mod-
ule
CPX-8DA-H 8DO-H
Output module
– 1byte/
8O
Digital multi I/O module CPX-8DE-8DA 8DI/8DO
Multi I/O mod-
ule
1byte/
8I
1byte/
8O
Analogue 2-off input module CPX-2AE-U-I 2AI
Analogue input
2 w ords/
32 I
–
Analogue 2-off out put module CPX-2AA-U-I 2AO
Anal ogu e out-
put
– 2 w ords/
32 O
1)
Modu l e iden ti fier in the operator un it or in the hardware confi gu rati on of the programmi n g software
2)
4-off modules (CPX-4DE and CPX-4DA) occupy 8 I or 8 O or 1 byte of address space ( 4 I/O or 8 bits
of address space remain unused)
Tab. 2/3: Example of address assignment of electric CPX modules (over view; bus node
inRemoteI/Ooperatingmode)–Part1
