2. Commissioning
2-9
Festo P.BE-CPX-PNIO-EN en 1407c English
Electric modules Module type Module
indicator
1)
Allocated address
space
(Designation) (Name) Inputs Outputs
Analogue 4-off input module
2)
CPX-4AE-I 4AI-I
Analogue input
4 wo r ds/
64 I
–
Analogue 4-off input module
2)
(temperature module for RTD sensors)
CPX-4AE-T 4AI-T
Analogue input
temp.
2words
or
4 wo r ds/
32/64 I
3)
–
Analogue 4-off input module
2)
(temperature module for TC sensors)
CPX-4AE-TC 4AI-TC
Analogue input
temp.
4 wo r ds/
64 I
–
Analogue 4-way input module
with pressure sensors
2)
(measuring range –1 ... +1 bar)
CPX-4AE-
P-B2
4AI-P-B 2
Analogue input
press.
4 wo r ds/
64 I
–
Analogue 4-way input module
with pressure sensors
2)
(measuring range 0 ... 10 bar)
CPX-4AE-
P-D10
4AI-P-D10
Analogue input
press.
4 wo r ds/
64 I
–
CP interface
2)
CPX-CP-4-FB CPI
CP interface
Max.
8 w ords/
128 I
4)
Max.
8 w ords/
128 O
4)
1)
Modu l e iden ti fier in the operator un it or in the hardware confi gu rati on of the programmi n g software
2)
No support for the additional function FSU
Note
When using the module in FSU operation, fast running up of the CPX terminal and compliance of
the PROF IN ET specification with regard to FSU are not guaranteed.
3)
Number of inputs switchable between 2 and 4
4)
Address space assignment dependent on the string allocation (4 byte I or 4 byte O per string)
Tab. 2/4: Example of address assignment of electric CPX modules (overview; bus node
in Remote I/O operating mode) – Part 2
